Petr Jurásek · Infrastructure & Platform Engineering

Building systems
that stay up.

MSc student in Applied Computer Science with a hands-on background in designing and operating production-grade infrastructure — hypervisors, VLAN-segmented networking, zero-trust access, and full observability stack, all self-built and self-operated.

Proxmox VE TrueNAS SCALE Traefik v3 Cloudflare Tunnel UniFi / VLANs Prometheus · Grafana · Wazuh
LinkedIn GitHub Forgejo About me ↓ View the lab ↓
2
cluster nodes
6
VLANs
25+
services
0
open WAN ports†

† excluding Plex and TeamSpeak 6 which are port-forwarded by design

Who's behind this

Petr Jurásek

I'm Petr, a final-year MSc student in Applied Computer Science at Palacký University in Olomouc. My academic background is in software development, but the work I find most compelling sits at the boundary between software and infrastructure — the layer where reliability, security, and operational discipline actually get enforced.

This homelab is how I close the gap between theory and practice. Every design decision here mirrors what you'd find in a production environment: VLAN segmentation with default-deny firewall policy, HA-aware service placement across a two-node Proxmox cluster, zero-trust external access via Cloudflare tunnels with no open WAN ports, and a full observability stack — Prometheus, Grafana, and Wazuh — that gives me real signal when something breaks. The goal is to build the muscle memory that textbooks don't provide.

I'm particularly drawn to roles that sit at the intersection of infrastructure reliability and data stewardship — network administration, hypervisor and Linux systems management, or data infrastructure roles focused on access control, dataset structuring, and keeping data secure at rest and in transit. If your team cares about doing these things properly, I'd like to talk.

Education
MSc — Applied Computer Science
Software Development · Palacký University in Olomouc
2024 – 2026

BSc — Information Technology
Palacký University in Olomouc
2021 – 2024
Open to
Network administrator Linux systems admin Hypervisor / virtualisation Data infrastructure Storage & ACL management Infrastructure engineer
01 / Infrastructure

Compute & storage

A two-node Proxmox VE cluster with shared TrueNAS storage, a dedicated backup server, and a Raspberry Pi quorum device to prevent split-brain during single-node failures.

lenovo1 · primary
Proxmox icon
Proxmox VE
10.169.91.70
Primary cluster node. Hosts most production LXCs. All DNS points to a pre-allocated keepalived VIP so failover requires zero DNS changes.
Proxmox 9VLAN 169cluster primary
lenovo2 · secondary
Proxmox icon
Proxmox VE
10.169.91.71
Secondary node and HA target. Planned host for the second Traefik node + keepalived, eliminating the reverse proxy as a single point of failure.
Proxmox 9VLAN 169HA failoverTraefik node 2 planned
truenas · primary datastore
TrueNAS icon
TrueNAS SCALE
10.169.69.69
Shared storage over NFS and SMB. Issues its own ACME certs natively. Single source of truth for persistent data.
NFSSMBACME certsVLAN 169
pbs · backup
Proxmox Backup Server icon
Proxmox Backup Server
10.169.173.99
Scheduled incremental backups for all LXCs and VMs with deduplication. Critical config paths verified per service. Stored on separate hardware from compute.
incrementaldedupscheduledVLAN 169
rpi5b · quorum
Raspberry Pi icon
Raspberry Pi 5B
10.169.91.72
Cluster quorum device — prevents split-brain when one Proxmox node becomes unreachable. With only two nodes, a tiebreaker is mandatory for HA to function correctly.
quorumsplit-brain prevention
ubiquiti · routing & switching
UniFi icon
UniFi Network
all VLANs
All switching and routing on UniFi hardware. Zone-based firewall with default-deny between VLANs and explicit allow rules only. No implicit inter-VLAN trust.
zone firewalldefault-deny6 VLANs
02 / Network Architecture

VLAN segmentation

Each workload class lives in its own VLAN with tailored firewall rules. This limits blast radius if any service is compromised and enforces least-privilege networking by default.

VLAN map — six segments
20
proxy
10.20.0.0/16
Ingress layer — sole entry point for all proxied traffic
TraefikCloudflaredkeepalived VIP 10.20.0.10
30
media
10.30.0.0/16
Media stack — isolated, no outbound to any other VLAN
PlexSonarrRadarrProwlarrSeerrqBittorrent
40
game
10.40.0.0/16
Game servers — isolated, port-forwarded directly bypassing Traefik
TeamSpeak 6AMP
50
services
10.50.0.0/16
Primary application VLAN — internal and split-horizon services
ImmichAuthentikOpenWebUIDocmostFoundryVTTNetboxN8N+more
55
exposed
10.55.0.0/16
Internet-facing services with stricter isolation from VLAN 50
NextcloudForgejoForgejo runnerPortfolio
169
infra
10.169.0.0/16
Infrastructure — hypervisors, storage, DNS, monitoring
ProxmoxTrueNASPBSTechnitiumPrometheusGrafanaWazuh
Firewall policy

Inter-VLAN rules

ALLOWDNS request from any VLAN → Technitium on VLAN 169
ALLOWVLAN 20 → backend VLANs on specific ports only
ALLOWCloudflare IPs → VLAN 20 only
DENYVLAN 30 (Media) → any other VLAN
DENYVLAN 40 (Game) → any other VLAN
DENYAll other inter-VLAN by default

WAN ingress

ALLOW9987/UDP → TS6 (voice)
ALLOW32400/TCP → Plex (direct streaming)
ALLOW3478, 5349 → Nextcloud (STUN/TURN)
DENYAll other inbound WAN traffic
Split-horizon DNS

Technitium DNS server

10.169.188.49 · Primary
10.169.139.122 · Secondary
10.154.222.213 · Offsite failover
Authoritative for local.screedy.com. Forwarder zone for screedy.com — local overrides resolve to Traefik VIP (10.20.0.10), unknown records forwarded to Cloudflare. Secondary Technitium syncs via zone transfer.

Domain conventions

*.local.screedy.com
Internal only. Technitium-authoritative. Never published to Cloudflare DNS. Unreachable externally by design.
*.screedy.com
Public or split-horizon. Technitium override for internal clients + Cloudflare public record for external clients. Same domain, different resolution.
03 / Services

Deployed applications

25+ self-hosted services across six VLANs, all accessible via Traefik with wildcard TLS certs issued through a Cloudflare DNS challenge — no open WAN ports required for web access.

Productivity & knowledge
Nextcloud icon
Nextcloud
split-horizon
nextcloud.screedy.com
Full self-hosted cloud suite — file sync, calendar, contacts, collaborative editing, and video calls. STUN/TURN port-forwards bypass Traefik for real-time communication.
VLAN 55Cloudflare tunnelSTUN/TURN
Docmost icon
Docmost
split-horizon
docmost.screedy.com
Collaborative wiki and documentation platform accessible externally via Cloudflare tunnel.
VLAN 50Cloudflare tunnel
Immich icon
Immich
internal
immich.local.screedy.com
Self-hosted Google Photos alternative with ML-powered face recognition, EXIF search, and mobile backup. NFS-backed storage on TrueNAS. Migrating from VLAN 169 to VLAN 50.
VLAN 50NFS storageML faces
Booklore icon
Booklore
internal
booklore.local.screedy.com
Self-hosted library management and e-book reader with metadata enrichment and reading progress tracking.
VLAN 50
Kiwix icon
Kiwix
internal
wiki.local.screedy.com
Offline Wikipedia and reference content server. Useful when external internet is unavailable.
VLAN 50Doomsday Preparation
AI & automation
OpenWebUI icon
OpenWebUI
split-horizon
ai.screedy.com
Web frontend for local LLMs served through LiteLLM proxy. Supports model switching, conversation history, and RAG pipelines from behind a Cloudflare tunnel.
VLAN 50Cloudflare tunnelLiteLLM
N8N icon
N8N
internal
n8n.local.screedy.com
Low-code workflow automation platform. Migrating to VLAN 50 with full Traefik integration and persistent NFS storage.
VLAN 50migrating
Changedetection icon
Changedetection
internal
changedetection.local.screedy.com
Website change monitoring with alerting. Tracks upstream service updates, CVEs, and infrastructure advisories.
VLAN 50monitoring
Infrastructure & operations
Traefik icon
Traefik v3
internal
traefik.local.screedy.com
traefik.screedy.com
Reverse proxy and TLS termination for all internal and split-horizon services. Wildcard certs via Cloudflare DNS challenge. Dynamic config hot-reloads with no restart. Proxmox HA configured for automatic failover.
VLAN 20Proxmox HAwildcard TLSmetrics
Authentik icon
Authentik
internal
auth.screedy.com
Identity provider and SSO. Forward auth middleware for Traefik planned — will protect services without built-in auth. Cloudflare tunnel exposure planned.
VLAN 50SSOforward auth planned
Netbox icon
Netbox
internal
netbox.local.screedy.com
Network source of truth — VLAN documentation, device inventory, and rack diagrams.
VLAN 50
Technitium DNS icon
Technitium DNS
internal
10.169.188.49
Primary DNS server with split-horizon zones. Authoritative for local.screedy.com, forwarder for screedy.com. Secondary node provides HA for DNS resolution.
VLAN 169split-horizonzone transfer
Forgejo icon
Forgejo
split-horizon
forgejo.screedy.com
Self-hosted git forge. Hosts all infrastructure and application code, including the CI/CD pipelines that deploy this portfolio. Actions runner in VLAN 55 SSHes into target LXCs for zero-downtime deploys.
VLAN 55Cloudflare tunnelActions runner
Media (VLAN 30 — isolated)
Plex icon
Plex
split-horizon
plex.screedy.com
Media server. Port-forwarded directly on 32400 for remote direct streaming — bypasses Traefik by design to avoid proxy overhead on large media streams. Isolated in VLAN 30.
VLAN 30port-forwardisolated
Arr stack
internal
*.local.screedy.com
Sonarr, Radarr, Prowlarr, Seerr, qBittorrent, Flaresolverr — fully automated media acquisition pipeline. All services reside in VLAN 30 with no outbound to other VLANs.
VLAN 30isolatedNFS storage
Gaming and entertainment
FoundryVTT icon
FoundryVTT
split-horizon
vtt.screedy.com
Self-hosted virtual tabletop for TTRPGs. Exposed externally via Cloudflare tunnel with WebSocket support through Traefik. Split-horizon DNS keeps latency low for local players.
VLAN 50WebSocketCloudflare tunnel
TeamSpeak 6 icon
TeamSpeak 6
port-forward
ts6.screedy.com
Voice communication server for gaming. Port-forwarded directly on UDP 9987 to minimize latency.
VLAN 40port-forwardisolated
04 / Security

Security posture

Defence in depth — from VLAN segmentation at the network layer up through zero-trust tunnels, automated TLS, SIEM alerting, and per-service access controls.

Network segmentation
  • Six VLANs isolate workloads by risk profile and purpose
  • Default-deny between all VLANs — explicit allow rules only
  • Media (30) and Game (40) have no outbound to internal services
  • VLAN 55 (Exposed) further isolates exposed services from VLAN 50
  • Traefik on VLAN 20 is the sole ingress point for proxied web traffic
Zero-trust external access
  • Cloudflare Tunnel — no inbound WAN ports for web services
  • All external traffic terminates at Cloudflare edge
  • *.local.screedy.com is never published to public DNS — unreachable externally by design
  • Cloudflared LXC isolated from backend VLANs — only permitted to reach Traefik
TLS everywhere
  • Wildcard certs for *.local.screedy.com and *.screedy.com via Cloudflare DNS challenge
  • No HTTP-01 challenge — WAN ports 80/443 remain closed
  • Cert managed centrally in Traefik, renewed automatically before expiry
  • HTTPS backends use serversTransport with appropriate cert verification settings
  • HSTS, XSS protection, frame options, referrer policy enforced via Traefik middleware
SIEM & access monitoring
  • Wazuh agent on Traefik LXC ships access logs and daemon logs as JSON
  • Custom Wazuh rules (IDs 100200–100207): brute force, 5xx storms, blocked access, slow response anomalies
  • Traefik access log captures ClientHost, X-Forwarded-For, DownstreamStatus, Duration, RouterName
  • Prometheus scrapes Traefik metrics — Grafana dashboards for request rates and error spikes
  • Rate-limit middleware on Traefik: 100 req/s average, burst 50
  • Basic auth on Prometheus endpoint enforced via Traefik middleware
05 / Observability

Monitoring & alerting

Metrics, logs, and security events aggregated into a coherent observability pipeline — so problems surface before they become outages.

Prometheus
Metrics collection
Scrapes Traefik (/metrics on :8080), Unpoller (UniFi network metrics), and itself. Basic auth enforced by Traefik middleware.
Grafana
Dashboards
Datasource pointed directly at Prometheus (bypasses Traefik auth layer). Dashboards for UniFi AP/client metrics, Traefik request rates, error rates, and response time percentiles.
Wazuh
SIEM / EDR
Agent on Traefik LXC with custom JSON decoder for Traefik access logs. Custom rule IDs fire on brute-force patterns, 5xx error spikes, blocked access events, and slow response anomalies.
Unpoller
Network metrics
UniFi controller exporter for Prometheus. Tracks per-client and per-AP traffic, signal quality, and channel utilisation. Pure exporter — no UI, port 9130 only.
Beszel
Host monitoring
Lightweight agent-based host monitoring. Tracks CPU, memory, disk I/O, and network per LXC and VM. Low overhead compared to full node_exporter setups.
Loki (planned)
Log aggregation
Planned addition to unify log shipping from all LXCs and VMs into Grafana. Currently logs are inspected per-host; Loki will enable label-based querying across the entire cluster.
06 / Engineering decisions

Why this setup?

The decisions that shaped this setup — and the trade-offs considered.

LXC over VM for most services
LXCs share the host kernel, making them faster to start and far cheaper on RAM — a meaningful constraint with two nodes. Proxmox HA works on LXCs, so failover is still automatic. VMs are reserved for workloads that genuinely need kernel isolation, like Nextcloud.
Cloudflare Tunnel instead of open WAN ports
No inbound WAN firewall rules for web services. Traffic terminates at Cloudflare's edge — the origin IP is never exposed. DDoS protection, WAF and rate-limiting handled by Cloudflare. The trade-off is a dependency on Cloudflare's availability for public-facing services, which is an acceptable risk for a homelab.
DNS challenge for wildcard TLS
Using the Cloudflare DNS-01 ACME challenge means no ports need to be open for cert issuance or renewal. A single wildcard cert covers all subdomains, and renewal is fully automated inside Traefik — no manual intervention ever needed.
VIP pre-allocated before HA is built
All DNS records point to 10.20.0.10 (future keepalived VIP) even before the second Traefik node exists. When lenovo2 gets its Traefik instance and keepalived is configured, no DNS records need to change — the cutover is operationally invisible.
Split-horizon DNS over separate domain names
Internal clients resolve service.screedy.com to the Traefik VIP via Technitium's forwarder zone. External clients get Cloudflare's public record. Same domain, different resolution path — no internal traffic hairpins through Cloudflare, and no UX difference for users.
Quorum device for a two-node cluster
Proxmox requires quorum to take HA actions. With only two nodes, a network partition creates a tie — without a tiebreaker, neither node can safely fence the other and HA stalls. The Raspberry Pi resolves this at minimal cost and power draw.
Separate VLAN 55 for internet-facing services
Nextcloud receives STUN/TURN port-forwards directly from WAN and runs the AiO container which exposes more surface area. Putting it in VLAN 55 rather than VLAN 50 limits the blast radius if the container is compromised — it cannot reach other application services.
07 / Technology

Full stack

Every technology actively used, managed, or operated in this environment.

Proxmox logo
Proxmox VE
Hypervisor
TrueNAS logo
TrueNAS
Storage OS
Proxmox Backup Server logo
PBS
Backup server
Traefik logo
Traefik v3
Reverse proxy
Cloudflare logo
Cloudflare
DNS / Tunnel / TLS
UniFi logo
UniFi
Switching & routing
Technitium logo
Technitium
DNS server
Prometheus logo
Prometheus
Metrics
Grafana logo
Grafana
Dashboards
Wazuh logo
Wazuh
SIEM / EDR
Authentik logo
Authentik
Identity / SSO
Docker Compose logo
Docker Compose
Container management
Nextcloud logo
Nextcloud AiO
Cloud suite
Immich logo
Immich
Photo management
Plex logo
Plex
Media server
OpenWebUI logo
OpenWebUI
AI frontend
LiteLLM logo
LiteLLM
LLM proxy
Netbox logo
Netbox
IPAM / DCIM
N8N logo
N8N
Workflow automation
Netbird logo
Netbird
WireGuard mesh
Docmost logo
Docmost
Wiki
FoundryVTT logo
FoundryVTT
Virtual tabletop
TeamSpeak logo
TeamSpeak 6
Voice comms
Matrix logo
Matrix Synapse
Chat server
Forgejo logo
Forgejo
Git forge / CI
Prowlarr logo
Prowlarr
Index management
Seerr logo
Seerr
Request management
And more...
08 / Roadmap

What's next

Active migrations and planned improvements to move the lab closer to a fully HA, zero-trust production posture.

In progress

Migrate Grafana, Prometheus, Wazuh, and Immich to VLAN 50 — consolidates all application services out of the infrastructure VLAN

Planned

Second Traefik node on lenovo2 + keepalived VIP (10.20.0.10) — eliminates the reverse proxy as a single point of failure
Authentik forward auth middleware in Traefik — SSO protection for services that lack built-in authentication
Grafana Loki — centralised log aggregation across all LXCs and VMs, replacing per-host log inspection
Netbird activation — WireGuard mesh overlay for secure cross-VLAN admin access and remote management without port-forwarding
Authentik public exposure — enables SSO for external users on split-horizon services via Cloudflare tunnel
